Reaction Arm RA B DR Z 45
Up to 4.800 Nm, suitable for DA/DE/DP - 48
Article number
80577
Availability:
PLARAD® - Reaktionsarm Standard | | Länge: 210 mm | Höhe: 130 mm | Länge Abstützfuß: 90 mm | Mtmax: 4800 NM
| Torque max. | 4.800 Nm |
|---|---|
| Variation | Basic |
| Product Group | DA/DE/DP |
| Product Assignment | DA/DE/DP1-2 48 |
| Gerätezugehörigkeit | DA/DE/DP1-2 48 |
| Number of Teeth (Z) | 45 Z |
| Length (L1) | 210,00 mm |
| Length (L2) | 90,00 mm |
| Width (B) | 60,00 mm |
| Height (H1) | 130,00 mm |
| Height (H2) | 15,00 mm |
