DE1docuplus-80
Electric Torque Wrench, 1.200-8.000 Nm, 885-5.900 ft.lbs, 1.1/2''-Square, AC230V, 50-60Hz, Torque/Rotation Angle Mode, including Reaction Arm, Case and Assembly Kit
Article number
80133S
Availability:
PLARAD®-DE1docuplus80
Electric Torque Wrench
incl. documentation of bolting cases via WLAN
Accessories:
Adjustable for:
- torque
- torque angle
- torque/torque angle
- torque-angle counter
Torque: 1.200 to 8.000 Nm
885 to 5.900 ft.lbs
Rotation speed: 2,50 UpM
Weight: 31 kg
Motor drive: 1,45 kW
Voltage: AC 230 V, 50 Hz
Square drive: 1.1/2"
Electric Torque Wrench
incl. documentation of bolting cases via WLAN
Accessories:
Adjustable for:
- torque
- torque angle
- torque/torque angle
- torque-angle counter
Torque: 1.200 to 8.000 Nm
885 to 5.900 ft.lbs
Rotation speed: 2,50 UpM
Weight: 31 kg
Motor drive: 1,45 kW
Voltage: AC 230 V, 50 Hz
Square drive: 1.1/2"
| Torque min. | 1.200 Nm |
|---|---|
| Torque max. | 8.000 Nm |
| Torque min. | 885 ft.lbs |
| Torque max. | 5.900 ft.lbs |
| Square | 1.1/2" |
| Mains Frequency | 50 Hz |
| Voltage | 230 V |
| Number of Teeth (Z) | 39 Z |
| Length (L1) | 566,00 mm |
| Length (L2) | 214,50 mm |
| Length (L3) | 106,00 mm |
| Height (H1) | 192,00 mm |
| Gear Ø (D1) | 101,00 mm |
| Output speed G1 | 2,50 UpM |
| Case | including |
Here you can find all relevant downloads for this product:
| Product range | Type | Description | Language | File extension | File size |
|---|
If you miss a download, please write us via our contact form.
Accessory parts for this product:
